Laminated Glass Impact Testing Machine Architecture , Impact Test Equipment

Laminated Glass Impact Testing Machine Architecture , Impact Test Equipment

Laminated Glass Impact Testing Machine Architecture , Impact Test Equipment

उत्पाद विवरण:

उत्पत्ति के प्लेस: चीन में बना
ब्रांड नाम: Infinity Machine
प्रमाणन: CE, ISO
Model Number: RS-8220LQ

भुगतान & नौवहन नियमों:

Minimum Order Quantity: 1 set
मूल्य: Negotiable
Packaging Details: Standard export wooden case with operation manual and video inside.
Delivery Time: Shipped in 15 days after payment
Payment Terms: D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 200 sets per month
अब से संपर्क करें
विस्तृत उत्पाद विवरण
Impact height: 600~1500mm adjustable Impact steel ball: 1040g±10g(∮63.5mm), 2260g±20g(∮82.5mm)
Specimen size: 610x610mm Steel ball falling direction: Vertically 90°±3°to the specimen
Sucking way: DC electromagnetic sucker Dimension: 1000X700x2000mm
Weight: About 300kg Power: AC220V 5A or specified by user



Laminated Glass Impact Testing Machine Architecture , Impact Test Equipment



Model: RS-8220LQ



Application:



This tester is design according to the standard GB/T9962-1999- 6.11, It satisfys the Architecture laminated glass impact testing requirement.



Standard:



JIS R 3205:1989,ISO/DIS12542 1,12543-6:1997,AS/NZS2208:1996,GB/T9962-1999



Specification:



 Model  RS-8220LQ
 Impact height  600~1500mm adjustable
 Impact steel ball  1040g±10g(∮63.5mm)
 2260g±20g(∮82.5mm)
 Specimen size  610x610mm
 Steel ball falling direction  Vertically 90°±3°to the specimen
 Counting cycles  0~999,999times
 Sucking way  DC electromagnetic sucker
 Dimension (WxDxH)  1000X700x2000mm
 Weight  About 300kg
 Power  AC220V 5A or specified by user
